NCERT Class 9 Constructions Concepts and Step-by-Step Methods

How do engineers design bridges or architects draw building plans with perfect accuracy? The answer lies in precise measurements and geometrical constructions. In mathematics, constructions help us draw accurate geometric figures using simple tools like a compass and a ruler. These methods ensure that shapes are drawn correctly and logically.

In this blog, you learn about basic constructions, angle constructions, and triangle constructions. By understanding these concepts step by step, students can easily create accurate diagrams and strengthen their geometry skills through examples and practice questions.

What Are Constructions in Geometry?

Geometrical construction is the process of drawing geometric figures accurately using specific instruments such as a ruler (straightedge) and a compass. In mathematics, constructions are used to create shapes like lines, angles, triangles, and circles with exact measurements and logical steps. Unlike freehand sketches, geometrical constructions follow precise rules so that the figure represents the given conditions correctly.

Importance of Precision in Mathematics

Precision is very important in geometry because even a small mistake in measurement or angle can change the entire figure. Constructions help students create accurate diagrams that match the mathematical conditions given in a problem. This accuracy is especially important when solving geometry problems, proving theorems, or designing shapes.

Difference Between Drawing and Construction

Students often confuse drawing with construction, but they are not the same.

• Drawing means making a rough or approximate figure just to understand the concept or visualize a problem.
• Construction means creating an exact geometric figure using a compass and ruler by following specific steps.

For example, a triangle drawn roughly by hand is just a drawing, but a triangle created using precise measurements and compass arcs is a geometrical construction.

Real-Life Applications of Geometrical Constructions

Geometrical constructions are not limited to textbooks. They are widely used in real-life fields such as:

• Architecture: Architects use geometric constructions to design buildings, rooms, and layouts accurately.
• Engineering: Engineers rely on precise geometric designs when constructing bridges, machines, and structures.
• Machine Design: Mechanical parts often require exact shapes and angles to function properly.
• Maps and Layouts: Surveyors and planners use geometric methods to create maps, road layouts, and city plans.

Example of a Simple Construction

One of the simplest examples of geometrical construction is constructing a circle using a compass.

1. Place the needle of the compass at a fixed point on the paper.
2. Adjust the compass to the desired radius.
3. Rotate the compass completely around the point.

This creates a circle where every point on the boundary is at the same distance from the center.

Similarly, students can construct a triangle by first drawing a base line and then using compass arcs to locate the third vertex. These step-by-step constructions ensure that the geometric figure satisfies the given measurements accurately.

Geometrical Instruments Required for Constructions

To perform geometrical constructions accurately, students need a few basic instruments that are usually available in a geometry box. These tools help draw precise lines, arcs, angles, and shapes required in geometry problems. Using the correct instrument properly makes constructions easier and more accurate.

Ruler (Straight Edge)

A ruler, also called a straight edge, is used to draw straight lines and line segments. In geometrical constructions, the ruler helps connect points and draw rays or sides of shapes like triangles and quadrilaterals. When doing pure constructions, the ruler is mainly used to draw straight lines rather than measure lengths.

Compass

A compass is one of the most important tools in geometrical constructions. It is used to draw arcs and circles. By fixing the needle at a point and rotating the pencil end, students can create arcs that help locate points, bisect angles, or construct triangles. The compass also helps transfer distances from one place to another on a diagram.

Divider

A divider looks similar to a compass but has two pointed ends instead of a pencil. It is used to measure and transfer distances between two points on a diagram. Dividers are especially useful when students need to compare lengths or mark equal distances during constructions.

Protractor

A protractor is used to measure and draw angles. It helps students construct angles such as 30°, 45°, 60°, 90°, and others accurately. While many classical constructions use only a compass and ruler, a protractor is helpful for checking or measuring angles.

Set Squares

Set squares are triangular tools used to draw special angles and perpendicular lines. Usually, a geometry box contains two set squares:

• One with angles 45°, 45°, and 90°
• Another with angles 30°, 60°, and 90°

These are helpful for quickly drawing right angles and specific angle measurements in diagrams.

You May Also Find This Useful

Master Class 9 Maths Formulas | Step-by-Step Guide

Tip for Students

When using a compass, make sure the needle is fixed firmly on the paper so that the radius does not change while drawing arcs. Always keep the compass opening steady to maintain accurate distances. When using a ruler, draw straight lines carefully and label points clearly. Practicing with these instruments regularly helps students perform constructions neatly and correctly.

Basic Constructions in Geometry

Basic constructions are the foundation of geometry. Many complex constructions, such as triangles and polygons, are created using a few simple construction techniques. By mastering these basic methods, students can easily perform more advanced geometrical constructions using a compass and ruler.

The most important basic constructions include:

Angle Bisector

• An angle bisector divides a given angle into two equal parts.
• It helps in constructing triangles and solving many geometry problems.
• It is created by drawing arcs from the angle’s vertex and joining the intersection point with the vertex.

Perpendicular Bisector

• A perpendicular bisector divides a line segment into two equal halves.
• It also forms a 90° angle with the line segment.
• This construction helps find the midpoint of a line and is used in triangle constructions.

Constructing Standard Angles

Students also learn how to construct common angles using a compass and ruler.

Examples include:

• 60° angle
• 90° angle
• 45° angle
• 30° angle

These angles are created using arcs and angle bisectors instead of measuring directly with a protractor.

Learning these basic constructions makes it easier for students to understand and perform advanced geometric constructions later in the chapter.

Book Your Free Demo Class Today

Construction 1: Bisector of a Given Angle

Concept Explanation

An angle bisector is a ray that divides a given angle into two equal angles. In simple terms, it splits an angle exactly in half. Angle bisectors are commonly used in geometric constructions and triangle problems because they help maintain equal angles and symmetry in figures.

Step-by-Step Construction

To construct the bisector of a given angle:

1. Draw the given angle, for example ∠ABC.
2. Place the compass at the vertex (B) and draw an arc that cuts both rays of the angle at points D and E.
3. Place the compass at points D and E, and draw two arcs with the same radius so that they intersect at a point F inside the angle.
4. Join the vertex B to point F using a ruler.

The ray BF is the required angle bisector.

Justification (Using Triangle Congruence – SSS Rule)

To prove that BF divides the angle into two equal parts:

• BD = BE (radii of the same arc)
• DF = EF (arcs drawn with equal radius)
• BF = BF (common side)

Therefore, ΔBDF ≅ ΔBEF by the SSS congruence rule.

So, ∠DBF = ∠FBE, which means BF is the bisector of ∠ABC.

Solved Example

Construct the bisector of a 70° angle.

Steps:

1. Draw ∠ABC = 70°.
2. With B as the center, draw an arc that cuts BA and BC at points D and E.
3. With D and E as centers, draw arcs of equal radius intersecting at F.
4. Join B and F.

The ray BF divides the 70° angle into two equal angles of 35° each.

Student Tip (Common Mistakes)

Students often make small mistakes during constructions. Avoid these errors:

• Changing the compass radius while drawing arcs.
• Not placing the compass needle exactly on the intersection points.
• Drawing very small arcs, which makes intersections unclear.
• Forgetting to label points properly.

Working carefully and keeping the compass radius fixed will help you create accurate constructions.

Construction 2: Perpendicular Bisector of a Line Segment

Concept Explanation

A perpendicular bisector is a line that divides a line segment into two equal parts and makes a right angle (90°) at the point where it intersects the segment. In other words, it passes through the midpoint of the line segment and is perpendicular to it.

Step-by-Step Construction

To construct the perpendicular bisector of a line segment:

1. Draw a line segment AB of the given length.
2. Place the compass at point A and draw arcs above and below the line segment.
3. Place the compass at point B with the same radius and draw arcs that intersect the previous arcs at points P and Q.
4. Join points P and Q using a ruler.

The line PQ intersects AB at point M, which is the midpoint, and forms a 90° angle with AB. Hence, PQ is the perpendicular bisector of AB.

Justification (Using Triangle Congruence – SAS Rule)

To justify the construction:

• AP = BP (arcs drawn with equal radius)
• PM = PM (common side)
• ∠APM = ∠BPM (formed by the intersecting arcs)

Therefore, ΔAPM ≅ ΔBPM by the SAS rule.

So:

• AM = MB, meaning M is the midpoint.
• ∠PMA = ∠PMB = 90°, proving PQ is perpendicular to AB.

Thus, PQ is the perpendicular bisector of AB.

Solved Example

Construct the perpendicular bisector of AB = 6 cm.

Steps:

1. Draw a line segment AB = 6 cm.
2. With A as the center and radius greater than half of AB, draw arcs above and below the line.
3. With B as the center and the same radius, draw arcs that intersect the previous arcs at points P and Q.
4. Join P and Q using a ruler.

The line PQ cuts AB at point M, dividing it into two equal parts of 3 cm each and forming a 90° angle with AB.

Construction 3: Constructing an Angle of 60°

Concept Explanation

A 60° angle can be constructed using a compass and ruler by forming an equilateral triangle. In an equilateral triangle, all three sides are equal, and each interior angle measures 60°. By using equal compass radii, we create points that form this triangle, which automatically gives us a 60° angle.

Step-by-Step Method

To construct a 60° angle at point A:

1. Draw a ray AB starting from point A.
2. Place the compass at A and draw an arc that cuts the ray AB at point D.
3. Without changing the compass radius, place the compass at point D and draw another arc intersecting the first arc at point E.
4. Join point A to point E using a ruler.

The angle ∠EAB formed is 60°.

Mathematical Reason

Since the arcs are drawn with the same compass radius, the distances AE, AD, and DE are equal. This forms triangle ADE, which is an equilateral triangle. In an equilateral triangle, all interior angles are equal, so each angle measures 60°. Therefore, ∠EAB = 60°.

Example

Construct a 60° angle at point A.

Steps:

1. Draw a ray AB.
2. With A as the center, draw an arc cutting AB at point D.
3. With D as the center and the same radius, draw another arc intersecting the first arc at E.
4. Join A and E.

The angle ∠EAB is the required 60° angle.

Start Your Free Math Class Today

Constructing Other Important Angles

Many angles in geometry can be constructed by combining or bisecting basic angles such as 60° and 90°. By using an angle bisector or combining two angles, students can easily construct several other important angles required in geometric problems.

Constructing a 90° Angle

A 90° angle is also called a right angle.

Steps:

1. Draw a line segment AB.
2. With A as the center, draw an arc cutting AB at point C.
3. With C as the center, draw another arc intersecting the previous arc at point D.
4. With A as the center again, draw an arc on the other side of AB.
5. Join the intersection point with A to form a perpendicular line.

The angle formed is 90°.

Example:
Construct a right angle at point A on line AB.

Constructing a 45° Angle

A 45° angle can be constructed by bisecting a 90° angle.

Steps:

1. First construct a 90° angle at point A.
2. Place the compass at A and draw an arc that cuts both rays of the 90° angle.
3. From the two intersection points, draw arcs that intersect each other.
4. Join A to the intersection point.

The angle formed is 45°, which is exactly half of 90°.

Example:
If ∠BAC = 90°, the bisector divides it into two angles of 45° each.

Constructing a 30° Angle

A 30° angle can be obtained by bisecting a 60° angle.

Steps:

1. First construct a 60° angle using a compass.
2. Draw an arc from the vertex cutting both rays of the angle.
3. Draw arcs from those intersection points.
4. Join the vertex with the arc intersection point.

This divides the 60° angle into two equal angles of 30°.

Example:
Construct ∠A = 60° and bisect it to get 30°.

Constructing a 15° Angle

A 15° angle can be constructed by bisecting a 30° angle.

Steps:

1. Construct a 30° angle first.
2. Draw an arc from the vertex intersecting both sides of the angle.
3. Draw arcs from the intersection points with equal radius.
4. Join the vertex to the intersection of these arcs.

This divides the angle into two equal angles of 15°.

Example:
If ∠A = 30°, its bisector gives two angles of 15° each.

Constructing 75°, 105°, and 135°

These angles can be formed by combining or subtracting basic angles.

75° Angle

• Construct 45° and 30° from the same vertex.
• The combined angle forms 75°.

105° Angle

• Construct 60° and 45° together.
• Their sum gives 105°.

135° Angle

• Construct 90° and add 45°.
• The resulting angle becomes 135°.

Example:
If ∠A = 90° and you add a 45° angle next to it, the total angle formed will be 135°.

By learning these methods, students can construct many angles without using a protractor, simply by using a compass, ruler, and angle bisector techniques.

Reserve Your Free Demo Class

Introduction to Triangle Constructions

Constructing a triangle requires at least three measurements. These measurements can include sides, angles, or a combination of both. With three correct measurements, a triangle can be drawn accurately and uniquely using a compass and ruler.

In geometry, triangle constructions are based on triangle congruence rules. These rules help ensure that the triangle formed is unique and exact.

Triangle Congruence Rules Used in Constructions

SSS (Side–Side–Side)

• A triangle can be constructed if the lengths of all three sides are given.
• The sides are drawn using compass arcs to locate the third vertex.

SAS (Side–Angle–Side)

• A triangle can be constructed if two sides and the included angle between them are known.
• The angle is drawn first, and the two sides are measured along its rays.

ASA (Angle–Side–Angle)

• A triangle can be constructed when two angles and the included side are given.
• The base side is drawn first, and the angles are constructed at each end.

RHS (Right angle–Hypotenuse–Side)

• This rule is used for right triangles.
• If the hypotenuse and one side are known along with the right angle, the triangle can be uniquely constructed.

Why Some Combinations Cannot Form a Unique Triangle

Not all combinations of three measurements can create a unique triangle. For example:

• If two sides and a non-included angle are given, more than one triangle may be possible.
• Sometimes a triangle cannot be formed at all if the measurements do not satisfy triangle conditions.

Therefore, when constructing triangles, it is important to use combinations that follow the congruence rules, ensuring that the triangle formed is accurate and unique.

Construction of Triangle When Base, Base Angle, and Sum of Other Two Sides Are Given

Concept Explanation

In this type of construction, the following measurements are given:

• Base BC
• Base angle ∠B
• Sum of the other two sides (AB + AC)

Using these values, we can construct triangle ABC. The idea is to first mark the total length AB + AC on the ray from point B, and then use geometric properties to locate point A so that the triangle satisfies the given conditions.

Step-by-Step Construction

1. Draw the base BC of the given length.
2. Construct the given angle at B, forming ray BX such that ∠XBC equals the given angle.
3. Mark BD = AB + AC on ray BX using a ruler.
4. Join points D and C with a straight line.
5. Construct an angle DCY equal to ∠BDC at point C.
6. Let the ray CY intersect BX at point A.

The triangle ABC formed is the required triangle.

Example Problem

Construct triangle ABC such that:

• BC = 6 cm
• ∠B = 50°
• AB + AC = 10 cm

Steps:

1. Draw BC = 6 cm.
2. At B, construct ∠XBC = 50°.
3. On ray BX, mark BD = 10 cm.
4. Join D to C.
5. At C, construct an angle DCY equal to ∠BDC.
6. Let CY intersect BX at A.

Join AB and AC to obtain the required triangle ABC.

Try a Free Math Class Now

Important Condition

This construction is not possible if:

AB + AC ≤ BC

This is because, according to the triangle inequality rule, the sum of any two sides of a triangle must always be greater than the third side.

Construction of Triangle When Base, Base Angle, and Difference of Two Sides Are Given

In this type of construction, the following values are given:

• Base BC
• Base angle ∠B
• Difference of the other two sides (AB – AC or AC – AB)

Depending on which side is larger, there are two possible cases.

Case 1: AB > AC

Here, the difference AB – AC is given.

Steps of Construction

1. Draw the base BC of the given length.
2. Construct the given angle at B, forming a ray BX such that ∠XBC equals the given angle.
3. Mark BD = AB – AC on ray BX using a ruler.
4. Join points D and C.
5. Draw the perpendicular bisector of DC.
6. Let the perpendicular bisector intersect BX at point A.
7. Join A to C.

Triangle ABC is the required triangle.

Example

Construct triangle ABC where:

• BC = 7 cm
• ∠B = 60°
• AB – AC = 2 cm

Steps:

1. Draw BC = 7 cm.
2. At B, construct ∠XBC = 60°.
3. On ray BX, mark BD = 2 cm.
4. Join D and C.
5. Draw the perpendicular bisector of DC.
6. Let it intersect BX at A.
7. Join A to C.

Triangle ABC is the required triangle.

Case 2: AC > AB

In this case, the difference AC – AB is given.

Steps of Construction

1. Draw the base BC of the given length.
2. Construct the given angle at B, forming ray BX such that ∠XBC equals the given angle.
3. Extend BX in the opposite direction of BC.
4. Mark BD = AC – AB on the extended line.
5. Join points D and C.
6. Draw the perpendicular bisector of DC.
7. Let the perpendicular bisector intersect BX at point A.
8. Join A to C.

Triangle ABC formed is the required triangle.

Both cases use the concept that point A lies on the perpendicular bisector of DC, which ensures the correct difference between the sides AB and AC.

Get Started with a Free Demo Today

Construction of Triangle When Perimeter and Two Base Angles Are Given

Concept Explanation

In this construction, the following measurements are given:

• Perimeter of the triangle (AB + BC + CA)
• Two base angles (∠B and ∠C)

The perimeter represents the total length of all three sides of the triangle. To construct the triangle, a line segment equal to the perimeter is first drawn. Then angle bisectors and perpendicular bisectors are used to locate the exact positions of the triangle’s vertices.

Step-by-Step Construction

1. Draw a line segment XY equal to the given perimeter of the triangle.
2. Construct angle ∠LXY equal to ∠B and angle ∠MYX equal to ∠C at points X and Y respectively.
3. Draw the angle bisectors of ∠LXY and ∠MYX. Let these bisectors intersect at point A.
4. Draw the perpendicular bisector of AX and let it intersect XY at B.
5. Draw the perpendicular bisector of AY and let it intersect XY at C.
6. Join A to B and A to C.

Triangle ABC is the required triangle.

Solved Example

Construct a triangle ABC such that:

• Perimeter = 11 cm
• ∠B = 60°
• ∠C = 45°

Steps:

1. Draw line segment XY = 11 cm.
2. At X, construct ∠LXY = 60°, and at Y, construct ∠MYX = 45°.
3. Draw the angle bisectors of both angles. Let them intersect at A.
4. Draw the perpendicular bisector of AX, meeting XY at B.
5. Draw the perpendicular bisector of AY, meeting XY at C.
6. Join A to B and A to C.

Triangle ABC formed is the required triangle with the given perimeter and base angles.

Fully Solved NCERT Example

Example:
Construct a triangle ABC where:

• BC = 6 cm
• ∠B = 45°
• AB + AC = 9 cm

Diagram Explanation

• Start with BC as the base of the triangle.
• At point B, construct the given angle (45°).
• On this ray, mark a point D such that BD = AB + AC (9 cm).
• Join D to C to help locate the actual position of A.

Construction Steps

1. Draw a line segment BC = 6 cm.
2. At B, construct ∠CBX = 45°.
3. On ray BX, mark BD = 9 cm.
4. Join D and C.
5. Draw the perpendicular bisector of DC.
6. Let it intersect BX at point A.
7. Join A to C.

Construction Reasoning

• Point D represents the sum of sides AB and AC.
• The perpendicular bisector of DC helps locate point A so that the triangle satisfies the given conditions.
• This ensures the triangle is accurately constructed using geometric rules.

Final Triangle Formation

• Join AB and AC.
• Triangle ABC is now formed satisfying:
  • BC = 6 cm
  • ∠B = 45°
  • AB + AC = 9 cm.

Join a Free Demo Session Today

Common Mistakes Students Make in Constructions

Using the Wrong Compass Radius

• Students often change the compass opening while drawing arcs.
• Tip: Fix the compass width carefully and avoid adjusting it until the step is completed.

Misplacing Arc Intersections

• Arcs may not intersect correctly due to incorrect placement or radius.
• Tip: Draw arcs clearly and ensure they intersect properly before marking points.

Skipping Perpendicular Bisector Steps

• Some students forget to construct the perpendicular bisector accurately.
• Tip: Always draw arcs from both endpoints with the same radius to locate the bisector correctly.

Incorrect Angle Marking

• Angles may be measured or drawn inaccurately.
• Tip: Use a protractor carefully and double-check the angle before continuing the construction.

General Tip:
Work slowly, label all points clearly, and check each step before moving to the next. This helps avoid errors and ensures accurate geometric constructions.

Exam Tips for Class 9 Constructions

• Label all points clearly in the diagram.
• Write construction steps in order.
• Mention geometric reasoning where needed.
• Practice diagrams regularly for accuracy and speed.

Practice Set – Basic Constructions

1. Construct the bisector of a 60° angle using a compass and ruler.
2. Draw a line segment AB = 6 cm and construct its perpendicular bisector.
3. Construct a 90° angle at a point on a given line.
4. Construct the bisector of a 120° angle.
5. Draw a line segment PQ = 8 cm and find its midpoint using a perpendicular bisector.
6. Construct a 45° angle using geometric construction.
7. Construct a 30° angle using a compass and ruler.
8. Draw a line segment of 7 cm and construct a perpendicular line through one endpoint.
9. Construct a 60° angle and then draw its angle bisector.
10. Draw a line segment AB = 5 cm and construct a perpendicular bisector to locate its midpoint.

Practice Set – Triangle Constructions

Level 1 – Easy (Base + Angle + Sum of Other Two Sides)

1. Construct a triangle ABC where BC = 5 cm, ∠B = 40°, and AB + AC = 8 cm.
2. Construct a triangle where BC = 6 cm, ∠B = 50°, and AB + AC = 10 cm.
3. Construct a triangle where BC = 7 cm, ∠B = 60°, and AB + AC = 11 cm.
4. Construct a triangle where BC = 4 cm, ∠B = 45°, and AB + AC = 9 cm.
5. Construct a triangle where BC = 8 cm, ∠B = 55°, and AB + AC = 12 cm.

Level 2 – Moderate (Base + Angle + Difference of Two Sides)

6. Construct a triangle where BC = 6 cm, ∠B = 50°, and AB – AC = 2 cm.
7. Construct a triangle where BC = 7 cm, ∠B = 60°, and AB – AC = 3 cm.
8. Construct a triangle where BC = 5 cm, ∠B = 45°, and AC – AB = 1 cm.
9. Construct a triangle where BC = 8 cm, ∠B = 70°, and AB – AC = 2 cm.
10. Construct a triangle where BC = 6 cm, ∠B = 55°, and AC – AB = 1.5 cm.

Book Your Free Demo Class Today

Level 3 – Advanced (Perimeter + Base Angles)

11. Construct a triangle with perimeter = 12 cm, ∠B = 60°, and ∠C = 45°.
12. Construct a triangle with perimeter = 14 cm, ∠B = 50°, and ∠C = 40°.
13. Construct a triangle with perimeter = 10 cm, ∠B = 45°, and ∠C = 60°.
14. Construct a triangle with perimeter = 15 cm, ∠B = 65°, and ∠C = 50°.
15. Construct a triangle with perimeter = 13 cm, ∠B = 55°, and ∠C = 45°.

How PlanetSpark Helps Students Learn Maths Better

• Interactive Math Learning
  PlanetSpark uses engaging activities and interactive lessons to make maths learning fun and interesting for students.
• Concept Clarity Through Visual Explanations
  Students understand difficult topics better with diagrams, visual examples, and simple explanations.
• Step-by-Step Problem Solving
  Teachers guide students through each step of solving problems so they clearly understand the method.
• Personal Guidance from Expert Teachers
  Experienced teachers provide individual attention and help students overcome learning difficulties.
• Confidence Building in Geometry and Maths
  Regular practice, feedback, and support help students build confidence in solving maths problems independently.

Final Thoughts on Geometric Constructions

Geometric constructions are an important part of learning geometry because they help students understand shapes, angles, and measurements accurately. In this chapter, students learn key skills such as constructing angles, bisectors, and triangles using a compass and ruler.

These skills improve logical thinking and precision in diagrams. Regular practice is essential to master these constructions. By practicing carefully and focusing on diagram accuracy, students can build strong geometry fundamentals and become confident in solving construction-based problems.

You May Also Read

Master Class 9 Maths NCERT: Complete Guide for Class 9th Students
